Primer for Silicone PIN001321

Name: Primer for Silicone PIN001321
Brand: Dongguan City Betterly New Materials Co., Ltd.

The material is a surface treatment which is made from modified silicone polymer. It is mainly used for surface treatment of silver coating, PC, ABS,ect. substrates to make the item have good adhesion on silicone after curing. Also it can improve anti sulfur property. It has advantages of simple operation, high transparency, fast drying, good adhesion,ect.

Get A Quote

Category: Primer for Silicone

Use Direction Of Product Manual for PIN001321

Take LED package as an example

Clean up the impurities of the holder cup
Dot coating the BTS-1911 inside the cup. Don’t spill, or there will be fault on lead bonding
Keep it at room temperature at least 15 minutes, put it in to over in 3 hours and bake it for 30 minutes at 180℃.
Keep the cured items in Nitrogen to guarantee that coating will not be polluted. And we suggest that use the cured item in 72 hours

The Performance Parameters Of Product Manual for PIN001321

Test item	Test condition and method	Result
Appearance	Visual	Colorless to light yellow transparent liquid
Film thickness(after curing)	Digital display altimeter	0.5-2um
Transmittance (after curing)	Ultraviolet-visible spectrophotometer	≥95%
Heat resistance	250℃/12 hrs	No yellowing, transmittance≥95%
Adhesion	4# cup, 25℃	10-15S

Other Illustrate Of Product Manual for PIN001321

Package: 3kg per can or 0.5kg per can

Storage: Stored in cool, dry and ventilated place at temperature of 0 to 25℃, humidity≤65％; Collection and storage it by galvanized metal, glass container; Stay far away from fire source

Shelf life: 6 months from production date, overdue material can be re- used after qualified
